Xaiv qhov tseeb linear qhia system yuav tsum ntsuas qhov yuav tsum tau ua rau precision, load peev xwm, mounting nto npaj, thiab ib puag ncig tej yam kev mob.
1. HG Series (Havy Load Ball-Type)
HG Series siv recirculating steel npas raws li cov khoom dov thiab ua haujlwm raws li kev lag luam thoob ntiaj teb tus qauv rau siab -precision, nruab nrab-rau- hnyav automation.
Elastic Compliance (Tus kheej-Kev sib tw):Vim nws cov ntsiab lus -contact geometry, lub pob-cov kabmob tsim muaj cov lej suav ntawm kev ua raws li elasticity. Qhov no tso cai rau cov blocks nqus me me mounting deg imperfections-xws li me ntsis flatness yuam kev nyob rau hauv welded los yog tsis yog- av thav duab- yam tsis muaj khi.
Kev sib txhuam qis ua haujlwm:Pob- hom kev qhia feem ntau pom muaj kev sib txhuam qis dua li cov lus qhia rau cov menyuam. Qhov no ua rau kev txhais cov kab ncaj nraim, qhov tsim hluav taws xob tsawg tsawg ntawm qhov siab ceev, thiab txo cov kev xav tau ntawm kev tsav tsheb.
Tus nqi -Kev ua tau zoo:Muab kev tsim khoom yooj yim, pob- hom kev qhia yog kev lag luam zoo, muab kev ua tau zoo heev - rau - tus nqi piv rau cov qauv kev lag luam.
Design Versatility:Cov chav tsev no yog qhov yooj yim los ntxuav thiab tswj, nrog ntau yam kev teeb tsa hauv lub tsheb (xws li Standard, Low-Profile, thiab Miniature) kom haum rau ntau yam kev txwv.
Ideal Applications:CNC routers, xaiv-thiab- qhov chaw robotics, ntoo / yas machining, thiab kev lag luam automation uas lub mounting ncej tsis precision- hauv av.
2. RG Series (High-Rigidity Roller-Type)
RG Series hloov cov pob zeb ib txwm muaj nrog cov cylindrical rollers uas cuam tshuam nrog txoj kev tsheb ciav hlau raws txoj kab. Nws yog qhov kev xaiv zoo rau siab -precision, hnyav-lub luag haujlwm muaj hlau txiav.
Superior Rigidity:Vim hais tias cylindrical rollers siv cov kab sib txuas, lawv tiv taus deformation nyob rau hauv siab loads. Qhov kev tsim no ua rau txo qis cov qauv deflection piv rau pob- hom kev qhia, ua kom muaj kev ruaj ntseg zoo thaum lub sijhawm ua haujlwm hnyav.
Exceptional Shock Resistance:Cov menyuam - hom kev qhia muaj kev tiv thaiv zoo rau cov kev cuam tshuam tam sim ntawd tau ntsib hauv cov hlau hnyav txiav lossis kev lag luam nias, txo qhov kev pheej hmoo ntawm kev sib tw brinelling (denting) nyob rau hauv kev poob siab heev.
High Moment Load Capacity:Qhov loj saum npoo ntawm cov menyuam yaus muab kev tiv thaiv zoo heev rau kev sib tw torsional thiab lub sijhawm thauj khoom, uas yog qhov yuav tsum tau ua kom ntev, cantilevered gantries.
Extended Fatigue Life:Kev faib cov khoom hla hla txoj kab sib txuas ua rau txo qis - qhov kev ntxhov siab ntawm qhov chaw ntawm txoj kev sib tw. Qhov no ua rau muaj txiaj ntsig zoo rau L10 ntsuas kev qaug zog lub neej nyob rau hauv tas li, hnyav - haujlwm 24/7.
Ideal Applications:Heavy-lub luag haujlwm tho txawv zeb, loj gantry milling tshuab, pob zeb lossis hlau sib tsoo chaw, thiab loj- nplai hlau stamping presses.
