Cov khoom piav qhia

SFU2004 Pob Screw yog ib qho tshwj xeeb precision tivthaiv engineered rau daim ntaub ntawv thov siab axial txhav thiab zoo positioning daws teeb meem. Los ntawm kev siv lub zog 20mm txoj kab uas hla ncej, cov qauv no txo ​​qis deflection thiab buckling nyob rau hauv hnyav loads. Tsis tas li ntawd, qhov zoo 4 hli txhuas ua kom muaj txiaj ntsig zoo tshaj plaws, ua kom cov motors me kom tsav cov khoom hnyav dua nrog qhov tshwj xeeb.

Qhov "Rigid" Precision Solution

• Txhim khu kev ruaj ntseg:Tsis zoo li cov sib zog 16mm series, 20mm ncej ntawm SFU2004 txhawb nqa ntev stroke ntev yam tsis muaj succumbing rau "ntses nplawm" (tseem ceeb ceev vibration).
• Kev daws teeb meem siab:Qhov zoo 4mm suab nce kev daws teeb meem rau 0.02mm ib kauj ruam tag nrho (siv tus qauv stepper motors). Qhov no ultra- txav tau zoo pab tshem tawm "cov kauj ruam artifacts" feem ntau pom thaum siv ntau dua -pitch screws.

Cov txheej txheem tsim khoom thiab cov txheej txheem
SFU2004 yog tsim los siv cov txheej txheem nruj kom ntseeg tau qhov tshwj xeeb hardness, straightness, thiab txhuas raug.

1. Kev xaiv khoom:Peb siv qib siab -qib, cua sov- kho tau cov hlau alloy, xaiv tshwj xeeb rau nws lub zog zoo dua thiab hnav tsis kam nyob rau hauv siab - load.
2. Xov xwm txheej:Cov xov yog tsim los ntawm Precision Cold Rolling (rau tus nqi - ua tau zoo C7 raug) lossis Precision Sib Tsoo (rau siab -cov qhab nia C5 / C3), xyuas kom meej 4 hli txhuas thiab zoo heev nto tiav.
3. Kev kho cua sov:Lub 20mm ncej undergoes induction hardening kom ua tiav qhov hardness ntawm HRC 58-62. Tom qab qhov no, cov txheej txheem kev ntxhov siab yog siv los tswj qhov kev ruaj ntseg thiab ncaj nraim hauv kev thauj khoom.
4.End Machining:Cov ncej kawg yog machined kom meej tolerances (xws li diameters, keyways, thiab threads) kom zoo kawg nkaus haum cov qauv kev txhawb pab xws li BK15 / BF15 los yog EK15 / EF15.
5.Precision Assembly:Lub pob txiv ntseej, suav nrog cov khoom siv rov ua dua tshiab thiab cov kabmob, ua tib zoo sib sau ua ke rau ntawm tus ncej. Rau cov qauv preloaded, lub nro sab hauv yog meticulously calibrated ua ntej lub chav tsev yog lubricated nrog siab - roj ua haujlwm.
6. Kev Tswj Xyuas Zoo:Txhua lub rooj sib txoos ua tiav kev tshuaj xyuas zaum kawg. Peb siv siab -cov cuab yeej ntsuas ntsuas ntsuas ntsuas qhov tseeb, axial rigidity, thiab rov qab ua raws.
